Installing a commercial-grade security system can feel intimidating, but it doesn't have to be. As a leader in Do-It-Yourself (DIY) surveillance systems we try to make it as easy as possible for you to install your cameras with ease, and precision. Montavue surveillance systems provide quality, reliable, and clear images for years to come.
Before you set up your security system we want you to evaluate all of your installation options so you can place your cameras in the best place possible to get the best views, protect the cameras from glare, and try to avoid the harshest areas for the camera.
What’s Included in Your Montavue Security Kit?
When buying a complete surveillance kit from Montavue you can rest assured you have everything you need to install your security system. We eliminate the guesswork by providing everything necessary for a robust, plug-and-play setup. Each complete system will come with the following:
-
100ft cable of Cat5e: Pre-terminated with weatherproof end.
-
Mounting Kit: Includes a drill template, screws, and wall anchors.
-
Network Video Recorder (NVR): Comes with a power adapter, HDMI cable for your monitor, mouse, SATA cables and screws for extra hard drives, and small ethernet cable.
The only thing you need is a monitor, but you can use any computer monitor via included HDMI cable. You will need common household tools such as a drill and screwdriver.
Your Step-by-Step Installation Guide
With your Montavue Complete NVR Security Systems ready, getting your hardware mounted correctly is straightforward. Follow these core steps for a smooth setup:
-
Test the Camera Unmounted: Before drilling, quickly connect your camera to the NVR to ensure it powers on and gives you a clear image.
-
Use the Drill Template: Stick the included drill template directly to your mounting surface to perfectly align your holes for the screws and wall anchors.
-
Run the Cable: Try to place the camera where you can run the cable through the wall to hide the cable so they aren’t visible to avoid someone cutting the cable. Common installs are in the ceiling, soffits, or on the side of buildings.
-
Adjust the Lens Angle: Once mounted, physically adjust the camera lens to capture your targeted field of view, making sure to avoid obstructions.
Expert Tips for Security Camera Placement
All Montavue cameras, except our indoor PTZ camera, are weatherproof with IP67 ratings. You can place your security cameras where you need them most. Consider these best practices, standard IP67 weather rating guidelines to protect your investment.
Maximizing Visibility and Deterrence
-
Avoid Glare: Avoid pointing directly at light sources – this may cause a glare.
-
Clear the View: Additionally, try and avoid where a tree or bush may sway close to the camera to avoid unnecessary motion alerts.
-
Strategic Deterrence: If you want to deter people, try and place in obvious areas, as just the sight of a security camera will deter many individuals.
Protecting Your Equipment
-
Stay Out of Reach: Place cameras out of reach – try and place cameras out of reach to reduce the threat of vandalism. As all of our cameras are made of a metal housing they are strong and can endure vandalism up to a certain amount, no camera is vandal resistant.
-
Seek Shelter: To get better images during rain, snow, or ice, try to place in sheltered areas. It also extends the life of your camera.
The Power of PoE: Simplifying Your Installation
We have made it as simple as possible to hook up your surveillance cameras. All you need to do is plug the one end of the included Cat5e cable that has the weatherproof connector into the camera, and the other end into the NVR, PoE switch, or router.
This single Cat5e cable carries both the power and video transmission. There is no need for separate power like the old analog systems. From there, you plug your NVR into power and directly into your router and your cameras should automatically appear within minutes.
Extending Your Security Coverage
Need to cover a massive commercial lot or a long driveway? You can go up to 600ft with 2 cables 300ft long split between a router or PoE switch. Using a Montavue PoE Switch helps you bridge those long distances with zero data loss.
Bridging Extreme Distances Wirelessly
For scenes that require long-distance transmission, such as parks, scenic spots, and factories, a wireless bridge provides a great solution. The Montavue Wireless Bridge delivers a strong signal with its enhanced antenna, allowing the peer-to-peer transmission distance to reach up to 3 km (9,842.52 ft).
Integrating this Montavue Wireless Bridge device into a point-to-point (PTP) or point-to-multipoint (PTMP) network design brings reliable performance with these powerful features:
-
High-Speed Throughput: The device has a throughput rate that is higher than 500 Mbps through its powerful hardware.
-
Simplified Power: The device also supports PoE input and PoE output (802.3af), effectively simplifying installation.
-
Weatherproof Design: IP67 rated, it is suitable for outdoor scenes and withstands severe weather.
-
Easy Management: With its built-in 2.4 GHz Wi-Fi, the device can be wirelessly accessed and configured.
DIY vs. Professional Installation
You may wish to use a local installer. However, we are confident that with our Montavue DIY security system you can have it up and running with just a little work. If you get stuck, look through our help guides, videos, or contact our tech support.
Peace of Mind is Just a Plug Away
Setting up a robust surveillance network doesn't require a degree in IT or a massive installation budget. By carefully planning your camera placement, hiding your cables, and taking advantage of our simple PoE technology, you can easily establish a professional-grade defense system.
Ready to upgrade your property's protection? Browse Montavue Security Systems today to find the perfect fit for your needs. If you want help designing a layout, Contact our Sales Team or request a custom quote right now!
